Specifications
Audio
DSP RMS Power: 35W x 6 (4Ω), 50W x 6 (2Ω)
DSP Resolution: 24 Bit
DSP Output Power RMS @ 4 Ohms (<1% THD +N): 35W x 6
DSP Output Power RMS @ 2 Ohms (<1% THD +N): 50W x 6
Distortion (THD): <0.005%
Damping Factor: >70
Operating Voltage: 10-14.4V
Sampling Rate: 48KHz
Signal Converter A/D: AKM7735
Signal Converter D/A: Cirrus Logic CS4344
Input
RCA / Cinch Sensitivity: 300mV
High Level Input Sensitivity: 3.5V
Impedance High Level: 240 Ohms
S/N Ratio Analog-in: 100dB
2 x RCA / Aux-in
6 High Level Speaker Input
1 x Remote-in
1 x USB
Output
8 x RCA / Cinch
6 High Level Speaker Output
1 x Remote-out
Voltage RCA / Cinch: 4V RMS
Features & Physical
Class AB Amplifier
Max. Output Power: 300W
Frequency Response: 20Hz-20kHz
Max. Current Draw: 30A
Dimension (W x H x D): 156 x 47.5 x 146mm
Weight: 0.94kg
