Amplify your car radio's electrical signal for a better coverage with Blaupunkt GTA475 that is solely German-made and high quality in function. Listening to radio will never be same again.
Specification :
• Amplifier Class : Class AB
• No of channel : 4/3/2
• No of PCB layer : 2
• Max total power : 160W x 2
• RMS power (4ohms) : 75W x 2
• RMs power (2ohms) : 120W x 2
• Max total power bridged (4ohms) : 240W x 2
• Frequency response : 10Hz - 50kHz
• Signal-To-Noise Ratio : =>96dB
• Voltage supply : 11 - 16V DC
• idling current : 0.8A
• Gain adjust : 200mV - 6V
• Crossover Type : Variable LPF
• Crossover Frequency (Low Pass Filter) : 32Hz - 250Hz
• Crossover Frequency (High Pass Filter) : 20Hz - 250Hz
• Crossover slope : -12dB/oct
• Hi-Volt input level control : 3V
• Lo-Volt input level control : 200mV - 6V
• Total harmonic distortion : <=0.05%
• RCA input : 4 Channel
• Speaker input : Yes
• Fuse : 40A x 2
• Power / Ground Terminal : Screw - Type
• Speaker terminal : Screw-Type
• Net Weight : 2.85Kg
• Dimension (W x H x D) : 260 x 165 x 58.5mm
