GTr 10150 A | Blaupunkt Active Subwoofer

RM 0.00

Quantity

- +

GTr 10150 A

Perfect Sound System

Blaupunkt has perfectly designed the ultimate sound system for its end users with German technology. Active Subwoofer GTR 10150 A is the ideal audio device for every vehicle. With German expertise, Blaupunkt has rooted the amplifier technology of Class AB into the subwoofer. In other words, there is no need for an external amplifier to be connected with this active subwoofer to give the radio the ultimate sound output experience. Equipped with a wired remote, you can easily tune your desired volume.

Max Output Power

Blaupunkt Active Subwoofer GTr 10150 A delivers a maximum outpower of 380 watts. This level of power is able to create an intensifying environment whenever you are listening to your favorite songs. Exciting as it sounds, Blaupunkt ensures your listening experience is satisfied.

Class AB Amplifier

GTr 10150 A has a built-in class AB amplifier that produces an output of 150 watts of RMS power. The built-in amplifier contributes to your listening experiences as it helps to boost the low-level audio signal and create powerful and better sound from your speakers as well.

Remote Control

Adjust to the desired volume with the wired remote control provided with GTr 10150 A. You can tune it to any volume you like, without worrying about the performance. Be it low or high volume, Blaupunkt Active Subwoofer GTr 10150 A will make your boost the performance of your audio devices.

Easily Fitted

Not only it can deliver such impactful performance, but GTr 10150 A is also able to be installed in different locations in the vehicle. One perfect spot is the car bonnet.

Wiring Diagram 1: High Level Input

Wiring Diagram 2: Low Level Input

Specifications

Subwoofer

Max. Output Power: 380W
Speaker Size: 10.0”
Cone Composition: Aluminium
Magnet Type: Ferrite
Wired Remoted: Included
Enclosure Housing Material: Aluminium Die-cast Sealed
Enclosure Dimension (LxWxH): 347 x 262 x 73mm
Enclosure Net Weight: 4.41kg

Amplifier

Amplifier Technology: Class AB
Normal Output Power (RMS): 140W
Sensitivity (In Car/1W): 92dB
Signal / Noise Ratio (dB): 91dB
Impedance: 2 ohms
Frequency Response: 20Hz – 150Hz
Low Pass Filter (LPF): 50Hz – 100Hz
Voltage: 14.4 (10V – 16V)
Phase Switch: 0 deg / 180 deg
Automatic On/Off (Hi & Lo): High Level Only
Audio in Sensitivity: Speaker Input (1.5V)/RCA Input (150mV)

Accessories

4 x Parker-Type Screws (4x20mm)
8 x M-Type Screws (4x5mm)
4 x Mounting Bracket (40x19mm)
1 x Wired Remote
